AT1315 laboratory gamma, beta energy spectrometer
Product introduction
l Detection of chemicals in water, food, agricultural, industrial and construction materials wood and environmental targets (soil, plants, etc.)γβ spectrum and radioactivity
l Two protected anticoincidence crystal scintillation spectrometers
l Detect metal radiation
l 1024 channels
l LED self-stabilizing system
l Maximum fitting method for processing energy spectrum
l PC displays sample energy spectrum in real time
l Simultaneous energy spectrum collection and processing
l PC multitasking
Product features
l identification137Cs, 90Sr, 40K, 226Ra, 232Th and other isotopes
l Built-inPC
l 1024 channel MCA
l software inRun under Windows
l PC spectrum processing using the best method
l Automatically calculate sample density
l Visible measured spectrum in real time
Technical parameters
energy range | γ | 50-3000 keV | Probe | NaI(Tl) Φ63×63 mm |
β | 150-3500 keV | plastic scintillatorΦ128×9 mm | ||
MCA channel number | γ spectrum | 1024 | inherent nonlinearity | ＜1% |
β energy spectrum | 1024 | Maximum input statistical error | 104s-1 | |
Specific activityBq/L（Bq/kg） | I-131 | 1—105 | continuous operation time | no less than24 hours |
Cs-134 | 6—105 | Measuring sample density range | 0.2—1.6g/cm3 | |
Cs-137 | 2—106 | Continuous Operation Calibration Instability | ＜2% | |
Sr-90 | 20—106 | Continuous operation data instability | ＜5% | |
K-40 | 20—2·104 | Measure operating time | ≤15min | |
Ra-226 | 3—104 | P=0.95 inherent measurement error | ±20% | |
Th-232 | 3—104 | Power requirements | 220V；50Hz | |
Detection lower limit90Sr (environmental background) | drinking water | 0.2Bq/l | required power | no more than100VA |
Milk, baby food | 1.5 Bq/l | 662keVγ energy response | ＜9.5% | |
Potatoes, bread, cereals, crops | 2.0 Bq/kg | Electromagnetic compatibility | IEC 61326-1:2005 | |
weight | Gamma radiation probe | 3kg | radio interference | EN 55022:2006 |
Beta radiation probe | 3kg | Operating temperature range | +10℃—+35℃ | |
protection unit | 120kg | relative humidity | ≤75% | |
Size | Gamma radiation probe | Φ98×371 mm | Environmental sample measurement container | wet sample 1 L (Marinelli cup) |
Beta radiation probe | Φ138×340 mm | Concentrated sample Flat type 0.5 and 0.1 L | ||
protection unit | Φ600×950 mm | Concentrated sample Flat type 0.2 and 0.03 L |
