UNIDOS Romeo Standard Reference Grade Dosimeter

UNIDOS RomeoStandard reference grade dosimeter

Advanced

as beyondA reference-level dosimeter meeting the performance requirements of IEC 60731, UNIDOS Romeo provides fast, reliable and highly accurate dose measurement in any situation. With its excellent stability, low noise and wide measurement range, it is ideal for dosimeter users looking for a self-contained instrument without compromising accuracy and performance.

Intuitive

This styleUNIDOS is the first dosimeter with a capacitive touch screen operating system and a simple multi-lingual user interface. All relevant settings can be accessed immediately with one touch, and the readings are clearly visible on the main screen from any angle.

automatic

Measurement tasks (such as selected measurement detectors, user-defined correction factors and measurement ranges) are stored as password-protected, user-specific documentation for future use, significantly reducing setup time.

Practical

Benefit from a range of practical features that make daily operations easier. Access previously stored measurements to calculate averages and standard deviations in real time; the detector database effectively manages up to100 different sets of detectors and their calibration data, and quick access to the detector library.

Technical specifications

Completely consistent withdownStandard reference grade dosimeter:

According toIEC 60731Standard radiation therapy dosimeter

Function According toIEC 61674 Standard Diagnostic Radiology Doseplan

According toBrachytherapy dosimeter according to IEC 62467-1 standard

According toIPEM* JSMP standard secondary standard dosimeter (needs to be calibrated in Japan)

channel 1

show 5-inch capacitive touch display，WVGA (800 x 480 Pixel), backlight

Supported languages Chinese, German, English, Spanish, Italian, French, Portugueselanguage, Russian, Japanese

QR code reading QR code scanner*

connect LAN, TCP/IP, 100 Mbit/s, IPv4/6

WLAN access point 802.11ac/b/g/n, WPA2, up to 800 Mbit/s* USB 2.0 Host, Type A (700 mA)

Size 201 mm (W) x 120 mm (H) x 253 (D) mm (includes legs)

weight 3 kg

Power supply (100 – 240) V, (50/60) Hz

Measuring range (according to IEC 60731, reference grade)

current 400 fA … 2.6 µA

charge 4 pC … 9.3 C

resolution

operating mode MEAS: Start manually/stop – continuous measurement

AutoMEAS: Start automatically/stop

Measurements are triggered by radiation, calculate dose from all recorded dataAutoMEAS & RESET: Automatic start with reset function/stopMeasurements are triggered by radiation and dose is calculated from the last measurement

INTEG: Cumulative dose over a predefined time interval

Repeatability < ± 0.25 % (£ ± 0.25 % IEC 60731)

long term stabilitysex < ± 0.1 % (£ ± 0.5 % more than one year, IEC 60731)

response time < 1.5 s (< 3 s (90 % response), IEC 60731)

nonlinear £ ± 0.25 % (£ ± 0.5 % IEC 60731)

Zero drift £ ± 0.25 % (£ ± 0.5 % IEC 60731)

bias voltage ± 400 V (± 0.5 V) @ 1 V interval

Zero adjustment 85 s

Configuration UNIDOS Tango Dosimeter, with M connector (order number L981629)，BNT connector (Order No. L981630) orTNC Companypick updevice(Order No. L981631)

Configuration contains Includes: stand,LAN/Ethernet cable, power cord、USB s line for field firmware updates
